Nylon Cable Gland

Product Introduction：

Our nylon cable gland series offers comprehensive and flexible options in materials, thread types, and customizations to meet diverse needs ranging from standard industrial applications to harsh environments. For the material, customers can choose standard nylon, which provides balanced mechanical and electrical performance for dry indoor conditions; eco-friendly nylon compliant with RoHS and other international environmental directives, suitable for export products or green building projects; flame-retardant nylon rated UL94 V0 for high-safety applications such as control cabinets, lighting fixtures, and railway transit, where the material self-extinguishes upon contact with fire to effectively reduce fire spread risks; and UV-resistant nylon, specially formulated with anti-UV additives to significantly improve weatherability and prevent cracking caused by prolonged sunlight exposure, making it ideal for outdoor installations. In terms of thread types, we support four mainstream standards simultaneously: PG thread (German standard) commonly found in traditional European equipment, M thread (metric) as the most widely used international standard, NPT thread (American standard tapered pipe thread) with self-sealing properties suitable for North American and pressure-fluctuating environments, and G thread (British standard parallel pipe thread) widely adopted in Commonwealth countries as well as pneumatic and hydraulic systems–enabling our glands to match most junction boxes, distribution panels, and equipment ports globally. Furthermore, we offer color customization and thread length customization: colors can be produced according to RAL codes or customer samples for batch orders, facilitating on-site cable identification or equipment appearance matching; thread length can be extended beyond standard dimensions specifically for thick-walled enclosures, insulated cold storage equipment, or thermal break doors, ensuring secure locking and effective sealing. All products are paired with high-quality sealing gaskets (available in NBR, silicone, or EPDM) and achieve up to IP68 protection rating, with precision molding and thread inspection to guarantee reliable connections. As a result, this series of nylon cable glands is widely used in control cabinets, solar photovoltaic systems, outdoor LED displays, railway transit, marine applications, automated production lines, and household appliances, serving as a trusted protection node in signal and power transmission links. For samples, technical drawings, or volume customization, please feel free to contact us.

Product Specifications:

Thread:M Thread, PG Thread, NPT Thread, G Thread(BSPP Thread)

Material: Nylon, Environment-friendly Nylon, Flame-retardant V0 Nylon, UV Resistant Nylon and PP Material.

Components: Cap, Seal, Body, Gasket, Nut

Protection level: IP68

Operating temperature: Static -40℃ to 100℃, or instantaneously heat-resistant up to 120℃; Dynamic -20℃ to 80℃, or instantaneously heat-resistant up to 100℃.

Color: Black, White, Gray, Red or other custom colors

Product Advantages:

Easy to install, free-tool

OEM, ODM Support

Flexible Material Options

Full Thread Compatibility
Customizable Color, Thread Length & Multiple Holes

High Ingress Protection

Wide Application Range

Enhanced Safety & Durability

Product Structure Diagram：

Product Parameters：

Model	Cable Range（mm)	Height of the Cap(mm） E	The OD of the Height（mm) E	The OD of the Thread（mm) C1	The Length of the Thread（mm) C2	Wrench Size（mm)	Diagonal Diameter of the Nut（mm) A
M8	2-5.5	11.9	12.2	8	7.5	13	14.6
M10	3-6.5	12.3	12.8	10	8	15	17
M12	3-6.5	14.8	15.8	12	8	18	19.5
M16	4-8	15.8	18.8	16	8	21	23.3
M18	5-10	17.3	21.7	18	8	22	26.3
M20	6-12	18.6	23.5	20	9	27	29.3
M22	10-14	18.6	26.1	22	10	27	31.7
M24	12-16	20	28.6	24	10	27	33.4
M25	13-18	20	28.6	25	10	33	39.2
M27	18-21	21.7	31.6	27	10	35	36.5
M30	16-21	21.7	34.7	30	11	35	40
M32	16-21	21.7	34.7	32	11	35	42.1
M36	18-25	25.6	41.6	36	15	42	48.3
M40	22-32	30	52.8	40	15	52	54
M50	32-38	30.5	61.1	45	15	60	66.8
M63	37-44	31.9	67.3	63	15	64	80.8
M75	45–52	39	71	75	25	89	97
M80	60–70	52	97	80	28	89	99
M88	60–70	52	97	88	28	98	108
M100	80–90	49	121	100	28	110	123
M114	80–90	49	121	114	28	123	136

PG7	3-6.5	14.8	15.8	12.5	8	18	19.6
PG9	4-8	15.8	18.8	15.2	8	22	23.3
PG11	5-10	17.3	21.7	18.6	8	24	26.3
PG13.5	6-12	18.6	23.5	20.4	9	27	29.2
PG16	10-14	18.6	26.1	22.5	10	30	31.7
PG19	12-16	20	28.6	24.8	10	31.2	33.7
PG21	13-18	21.7	31.6	28.3	10	36	39.2
PG25	18-21	21.7	34.9	30	11	37	40.3
PG29	18-25	25.6	41.6	37	15	45	49.9
PG36	22-32	30	52.8	47	15	57	62.5
PG42	32-38	30.5	61.1	54	15	65	71.3
PG48	37-44	30.5	64.8	59.3	15	70	76.8
PG63	44-50	41.3	76.4	71	28	80	89.7

G1/4	4-8	15.8	18.8	13.1	15	20	22
G-3/8	5-10	17.3	21.7	16.6	15	23	26
G-1/2	6-12	18.6	23.5	20.9	8	27	30
G-3/4	13-18	21.7	31.6	26.4	15	33	36
G-1	18-25	25.6	41.6	33.2	15	42	46
G-1-1/4	25-33	30	52.8	41.9	15	49	55
G-1-1/2	32-38	30.5	61.1	47.8	15	56	61
G-2	37-44	30.5	64.8	59.6	15	70	75

NPT1/4	4-8	15.8	18.8	13.1	15	20	22
NPT-3/8	5-10	17.3	21.7	16.6	15	23	26
NPT-1/2	6-12	18.6	23.5	20.9	8	27	30
NPT-3/4	13-18	21.7	31.6	26.4	15	33	36
NPT-1	18-25	25.6	41.6	33.2	15	42	46
NPT-1-1/4	25-33	30	52.8	41.9	15	49	55
NPT-1-1/2	32-38	30.5	61.1	47.8	15	56	61
NPT-2	37-44	30.5	64.8	59.6	15	70	75
